HDE-K
Heavy Duty Tweezers Station

The HDE-KD Tweezers Station has been designed to reduce the soldering time in applications that require a large amount of heatspan.

Some examples of applications are: coaxial cable shields soldering in telecommunication antennas, soldering of large copper conductors in medical imaging scanners, battery terminals, large-size capacitors, etc.

This station is supplied with 2 HDE-U Control Units, the most powerful soldering unit in the JBC range, and with HT470-A HD Thermal Tweezers which use the C470 Cartridge Range.

The Control Unit provides the best soldering quality thanks to the JBC Exclusive Heating System and, additionally, Intelligent Sleep & Hibernation Modes help to extend life of tips. It also allows direct connection with JBC Fume Extractors.

Aditionally, includes the SCH-A Cartridge Holder to store up to 16 cartridges and tips nearby.
HDE-K - Heavy Duty Tweezers Station
Selectable Temperature
90 to 500 ºC / 190 to 932 ºF
Idle temp. stability (still air)
±1.5ºC (±3ºF)
Meets and exceed IPC J-STD-001F
Temp accuracy
±3% ( using reference cartridge)
Temp adjustment
±50ºC (±90ºF) Through station menu setting
Connectivity
USB-B (rear)
Software PC / Traceability
USB-A (front)
Firmware update Soldering Graphics management
RJ12 Connector
ESD/EOS
Tip to ground vol./ resist.
Meets and exceed
ANSI/ESD S20.20-2014 IPC J-STD-001F
Power supply
Peak power
250 W - 42 V
Ambient operating temp.
10 to 50 ºC / 50 to 120 ºF

Dimensions and weight
Premium Stations
232 x 148 x 128 mm / 7.27 kg.
9.13 x 5.83 x 5.04 in / 16.02 lb.
Package
620 x 385 x 395 mm / 9.68 kg.
24.41 x 15.16 x 15.55 in / 21.33 lb.
Cartridge Range
Other Compatible Items
