    SF Station
    Automatic Solder-Wire Feeder

    This Solder-Wire Feeder allows you to feed solder wire automatically from any position.

    This station is supplied with GSF10V to feed solder wire of Ø 1 mm and is furthermore compatible with solder wires from Ø 0.4 mm up to Ø 1.8 mm, using the respective Solder Wire Guide Kit. It features Solder Wire Perforation, allowing better flux flow and outgassing, thus avoiding projections and Foreign Object Debris (FOD).

  • • 3 different working modes:
    Continuous Mode, Discontinuous Mode and Program Mode which allows configuration of dispensed wire speed and length



    • SF - Automatic Solder-Wire Feeder Station
    Don’t believe us...
    TRY IT!
    REFERENCES
    SF-110VB
    100-120V & Ø1mm
    SF-210VB
    230V & Ø1mm
    PRODUCT COMPOSITION
    1
    SF Automatic Solder-Wire Feeder
    SPECIFICATIONS
    Solder wire diameter
    1mm / 0.04 in with GSF10V
    Max. wire length
    25 mm / 1 in
    Max. speed
    120 mm/s / 4.72 in/s Forward & Reverse
    ESD safe
    Meet ANSI/ESD S20.20-2021
    USB-B (front)
    Firmware update and PC communications
    Robot connector
    Compatible Solder Reel
    Weight
    up to 1 kg / 2.2 Ib
    Diameter
    max. 80 mm / 3.15 in
    Height
    max. 75 mm / 2.95 in
    Reel stand axis
    Ø 10 mm / Ø 0.4 in
    Weight and dimensions
    Control Unit
    140 x 150 x 120 mm / 2.32 kg.
    5.51 x 5.91 x 4.72 in / 5.11 lb.
    Package
    368 x 368 x 195 mm / 3.23 kg.
    14.49 x 14.49 x 7.68 in / 7.12 lb.
