More functions,
better quality in soldering


The incorporation of the new functions and the possibility to modify more parameters means you can get the best quality results in the soldering joints with graphics in real time, partial counters, tool port monitoring...

From customizing
to total control


Our soldering and rework equipment has a great capacity to suit your needs.
You can manage and monitor groups of stations remotely thanks to their multiple connections: USB, LAN, Robot and peripheral modules.
It can also store settings which can be easily exported.

The best support
to your work


Use our innovative applications to complement your work such as the microscope, file storage, unit converter, calculator, video and even a station help to assist you at anytime.

(1.79 Mb)

Easy-to-use Menu
The TFT Screen facilitates user interaction and its interface provides fast access to the station settings
The Intuitive Menu makes work a more comfortable process
Click on the following icons to see the benefits:
pantalla capacitiva Ok menu info
Station
Adjust station parameters and personalize the new functions

+ More info

Tools
Set diferent tools for each port

+ More info

Peripherals
Join station ports with pedals and modules: Desoldering Pump, Nitrogen Flow Regulator, Fume Extractor,...

+ More info

Counters
Register total and partial hours for each port: work, sleep, hibernation hours,...

+ More info

Graphics
Monitor your work processes with power and temperature data in real time

+ More info

Reset
You can reset the stations paramenters to default values
Info
Consult the comprehensive help for each parameter
Station Icon
Customizable
Station
Set the station parameters according to your work needs and personalize the new functions
Move the mouse over the red point to see the new functions
Name
Asign a name to the station for easy identification
Robot
Enable this option when you connect a robot system on the station via RJ12 connector
PIN
Easily enable or disable the PIN option
Partial Reset
Reset to default values of the station (option also included in tools and counters menu)
Info
Get the technical information of the station
JBC - Station Customizable Station Info Station Reset Station Name Robot Station Name
Tools Icon
Move the mouse over the red point and see the new functions
Tools Preset
Set the tool before connecting.

The stored settings are activated only when the station detects a tool is connected
Tool
Shows the detected tool and the settings are applied
JBC - Tools Preset Tool
Counters Icon
Partial Counters
Display the hours worked in each cycle
Move the mouse over the red point and see the new functions
JBC - Partial counters Port Partial & Total Port PaArtial Reset Cycles
Partials
Displayed hours worked in each cycle
< / > Change Ports
Monitor the counters for each port without having to return to the Home screen
Cycles
How many Sleep or Desoldering cycles were performed partially and totally?
Partial Reset
Reset the partial counters of the station
Tools Icon
Peripherals
Join station ports
with 1 module
and 1 pedal

Select the most
appropiate peripherals
according to your soldering
or desoldering needs
With Excellence stations
you can connect a periphal
for each port
Set the working mode
of the Pedal to activate
a module or the Sleep
feature of the tool
JBC - Peripherics
2 Tool Control Unit
DDE
Electric
Desoldering Module
MSE
Penumatic
Desoldering Module
MVE
Nitrogen
Flow Regulator
MNE
Fume
Extractor Switch
FSE
Pedal
P-005
Station
Graphics
Monitor your work with power and temperature data
in real time
Analysis of the soldering process
It helps you select the best tip for your work and see the quality of each soldering joint
Temperature
---- Power
JBC - Analysis of the soldering process
Station
Communication Station - PC

USB-A
Software Updating

Insert a USB Flash drive
with the station's latest version.
Download it from www.jbctools.com

Export Graphics
Insert a USB flash drive into a USB-A connector
before starting the graphics and data will be copied in CSV format
JBC - USB Connector

USB-B
The incorporation of a USB Connector
on all stations and Control units
allow you to manage your job
remotely from a PC.

The most innovative technology to take your work beyond the station.

Update station software
www.jbctools.com/software.html

Manage and monitor parameters via PC
www.jbctools.com/manager.html
JBC - USB Connections
Station
Robots
Automate
the soldering process
and control the settings
from your Robot
For very repetitive jobs
requiring precision
JBC - USB Connector
Connection RJ12
Tools Icon
B·Net

Your Soldering Net
Configure and control
all your company's
JBC stations via PC and Centralize the control of your work via USB

Organize groups of
stations and set all the
parameters at the
same time
JBC - Peripherics
4 Tool Control Unit
DME
Any
JBC
station
Connect the stations
and the PC will detect them
automatically
4 Tool Control Unit
DME
4 Tool Control Unit
DME
2 Tool Control Unit
DDE
4 Tool Control Unit
DME
Nano stations
NANE / NASE
Download JBC Manager software and the User Manual from
www.jbctools.com/manager.html
